Arduino Mega Sensor Shield V1.0 for Arduino Mega projects

Name: Arduino Mega Sensor Shield V1.0 for Arduino Mega projects
Brand: satkit
SKU: J030206-SENMEG
Price: 5.84 EUR
Availability: InStock

Brand: satkit

Be the first to review this product

Save 5% Was: 6.15 €

5.84€

VAT included (Ex VAT: 4.75 €)

Volume Discounts

Quantity	Price	Save
2+	5.90 €	-4%
10+	5.60 €	-9%
20+	4.92 €	-20%

Only 4 left in stock - order soon!

Standard delivery Wed, Apr 29 - Fri, May 1

Express delivery Mon, Apr 27 - Tue, Apr 28

30-day returns

Quantity

Free returns within 30 days

Secure transaction

Free Delivery Shipping from €4.99

Easy Returns 30 day return policy

Secure Payment 100% secure checkout

Quality Guarantee Original products only

The Arduino Mega Sensor Shield V1.0 is an essential accessory for enthusiasts and professionals working with the Arduino Mega board. This shield makes it easy to connect a range of electronic sensors and modules in an organised way, helping with the development of electronics and robotics projects.

Key features:

Designed specifically for the Arduino Mega board.
Allows easy and secure connection of sensors and modules.
Optimises space and wiring in electronic projects.
Manufactured by satkit, recognised for its quality in electronic components.

Technical specifications:

Model: V1.0
Compatibility: Exclusive with Arduino Mega
Function: Shield for sensor connection

Typical uses:

Robotics projects that require multiple sensors.
Automation and control using Arduino Mega.
Development of electronic prototypes with various sensors.

Compatibility: This shield is compatible only with the Arduino Mega board, making it easy to connect sensors and modules directly without the need for additional soldering or complex cables.

With the Arduino Mega Sensor Shield V1.0 from satkit, you can enhance your electronics and programming projects, making sensor integration faster and more efficient.

Designed for the Arduino Mega board
Makes it easier to connect sensors and modules
Optimises wiring in electronic projects
Manufactured by satkit to a high standard
V1.0 model for versatile projects

Customer Questions & Answers

What are the main materials, dimensions and weight of the Shield, and what is included in the box?

The Shield is made from fibreglass PCB (FR4), nickel-plated brass male pins and lead-free solder. Its dimensions are approximately 102 mm x 53 mm x 16 mm and it weighs around 35 g. The box generally includes only the Sensor Shield board; cables and sensors must be purchased separately.

What are the operating current limits per pin and the precautions to avoid damaging the Shield?

Each pin supports up to 40 mA (limited by the Arduino Mega microcontroller, not by the Shield). It is recommended not to exceed a total of 200 mA per GND or VCC pin group to avoid overheating or damage. The Shield does not provide internal short-circuit protection.

What is the Arduino Mega Sensor Shield V1.0 used for?

It is used to make it easier to connect sensors and modules to the Arduino Mega board, simplifying the development of electronic projects.

Is it compatible with other Arduino boards?

No, this shield is designed exclusively for the Arduino Mega board.

What type of sensors can I connect?

You can connect various sensors compatible with Arduino Mega, such as temperature, humidity, motion sensors, among others.

Does it include cables or sensors?

No, the shield is only a connection board; cables and sensors must be purchased separately.

Who manufactures this product?

The Arduino Mega Sensor Shield V1.0 is manufactured by satkit, a recognised brand in electronic components.
