Programmable 30V 5A Mlink PPS3005 Bench Power Supply
Brand: Mlink
VAT included (Ex VAT: 81.50 €)
Volume Discounts
| Quantity | Price | Save |
|---|---|---|
| 10+ | 98.40 € | -2% |
The programmable 30V 5A Mlink PPS3005 bench power supply is an electronic unit designed to provide a stable, adjustable power supply, ideal for electronics, laboratory and repair applications. Its LCD panel clearly displays voltage and current values, while its programmable capability enables precise control through USB and RS232 connections.
Main features:
- Input voltage: AC 220V ±10%, 60Hz.
- Output voltage range: 0 to 30V DC.
- Output current range: 0 to 5A.
- Maximum power: 150W.
- High adjustment resolution: 10mV for voltage and 1mA for current (2mA if current >3A).
- High stability and low drift, with temperature coefficient of 300PPm + 3mV/mA.
- Built-in protections: overvoltage protection (OVP), overcurrent protection (OCP) and overtemperature protection (OTP).
- Connection interface: USB and RS232 for remote control and programming.
- Adjustment accuracy: voltage ≤0.1% + 20mV, current ≤0.5% + 5mA.
- Low ripple: voltage ≤1mVrms (≤2mVrms >3A), current ≤3mArms (≤6mA >3A).
Typical uses:
- Electronics laboratories for circuit testing and development.
- Repair and maintenance of electronic devices.
- Educational projects and electronics experimentation.
- Applications requiring a programmable and stable power supply.
Compatibility and accessories:
- Compatible with computer control systems via USB and RS232 connection.
- Includes power supply, user manual in English and power cable.
This Mlink PPS3005 programmable power supply is an affordable and advanced option for those seeking precision and stability in their electronics projects. Although it is currently out of stock, we recommend checking back for future availability or browsing alternative products in our store.
- Adjustable 0 to 30V DC output with high precision.
- Adjustable current output up to 5A with 1mA resolution.
- LCD digital display for clear parameter viewing.
- USB and RS232 connection for remote control and programming.
- Built-in protection against overvoltage, overcurrent and overtemperature.
- 150W maximum power suitable for electronics projects.
- Low ripple and high stability for reliable results.
- Includes power supply, English manual and power cable.
Customer Questions & Answers
What electrical requirements and compatibility are needed to install and operate this power supply?
It requires a 220 V AC ±10% 60 Hz power supply. The output is a single-channel DC output. For programmable control, it is compatible with computers via USB or serial port; specific drivers may be required depending on the operating system (Windows recommended).
What are the dimensions, weight and exact box contents when buying the Mlink PPS3005?
The approximate dimensions are 265 mm x 110 mm x 150 mm and the weight is between 4 and 5 kg. The package generally includes the power supply, mains lead, USB cable, spare fuse and user manual. It is recommended to check the contents with the supplier to confirm the included accessories.
In what real-world use cases is it preferable to choose the Mlink PPS3005 over more basic alternatives?
This model is preferable in laboratories, education and production environments where fine adjustment, repeatability and automated control are needed (circuit testing, electronics development and calibration). Compared with basic alternatives, it stands out for its programmability and precision. For manual work or limited budgets, a standard power supply may be sufficient.
What is the output voltage and current range of the Mlink PPS3005 power supply?
The output voltage range is 0 to 30V DC and the current range is 0 to 5A.
What connections does the Mlink PPS3005 programmable power supply have?
It has USB and RS232 connections for remote control and programming from a computer.
What protections does this power supply include?
It includes overvoltage protection (OVP), overcurrent protection (OCP) and overtemperature protection (OTP).
Is the Mlink PPS3005 currently available?
This product is currently out of stock. We recommend checking future availability or alternative products.
What accessories are included with the Mlink PPS3005?
The power supply, a user manual in English and a power cable are included.
