Aoyue Int720 Professional Infrared Soldering System for Precise Repair
Brand: Aoyue
VAT included (Ex VAT: 1,380.00 €)
Product description
The Aoyue Int720 infrared soldering system is a professional soldering station that integrates three essential functions into one unit: soldering iron, preheater and infrared soldering tool. Designed to deliver precise and efficient control in electronic repair processes, this system uses advanced infrared wave heating technology that avoids common issues associated with hot air use, such as the movement of nearby components.
Main features
- 3-in-1 system: Combines soldering iron, preheater and infrared tool for complete repair work.
- Adjustable tool holder: Provides stability and precision during soldering.
- Visual protection: Includes a panel that protects the user's vision from dangerous light rays.
- Programmable digital control: Allows precise adjustment of time and temperature for infrared soldering, soldering iron and preheater.
- Infrared wave heating technology: Prevents component movement and improves soldering quality compared with traditional hot air methods.
- Closed-loop temperature control tuning fork: Ensures instant and accurate monitoring during the process.
Technical specifications
- Station: 220V power supply, 600W consumption, dimensions 348x242x98 mm.
- Infrared tool: 165W consumption, temperature range 0-480°C, IR heating element halogen tube, output power 15VAC.
- Soldering iron: 70W consumption, temperature range 200-480°C, ceramic heating element, output power 24VAC.
- Preheater: 400W consumption, maximum temperature 350°C at the source, dark infrared heating element, output power 220VAC.
Recommended uses
This system is ideal for technicians and professionals working in electronic component repair, especially in BGA reballing and precision soldering processes. Its infrared technology ensures even and controlled heating, reducing risks and improving work quality.
Compatibility and accessories
Compatible with a wide range of electronic components and printed circuit boards. For accessories and spare parts, please refer to the manufacturer's official website www.aoyue.com.
Important note
The heating element and tips are excluded from warranty.
- 3-in-1 system: integrated soldering iron, preheater and infrared tool
- Programmable digital control of time and temperature for each function
- Infrared wave heating technology that prevents component movement
- Stable and adjustable infrared tool holder for greater precision
- Built-in visual protection panel against dangerous light rays
- Total power consumption: 600W with 220V power supply
- Compact dimensions: 348x242x98 mm
- Infrared temperature range: 0-480°C with halogen tube
- Soldering iron with ceramic element and 200-480°C range
- Preheater with dark infrared element and maximum temperature of 350°C
Customer Questions & Answers
What exactly is included in the box for the Aoyue Int720 system, and what are its dimensions and weight?
Typical contents include the base station (348 × 242 × 98 mm), adjustable tool holder, infrared soldering instrument, soldering iron with ceramic element, preheater and optical protectors. Total weight is around 5 to 10 kg. It is advisable to confirm the exact accessories included with the supplier.
What power supply requirements does it have, and is it compatible with standard domestic installations in Latin America?
The station requires a 220 V AC power supply and has a maximum consumption of 600 W. It is not directly compatible with 110 V mains, which are common in some Latin American countries; an appropriate transformer is required if the mains supply does not match that voltage.
What are the operating temperature ranges for each function (infrared soldering, soldering iron, preheater), and how fine is the adjustment?
The infrared unit operates from 0 to 480 °C, the soldering iron from 200 to 480 °C, and the preheater up to 350 °C. All temperatures can be adjusted digitally for precise control. This makes it suitable for different types of electronic components, although for very sensitive components or multilayer boards, additional monitoring is recommended.
What type of maintenance does the station require, and which parts usually need replacement or periodic inspection?
It is recommended to regularly clean filters, supports and the infrared reflective surfaces. The heating elements (halogen tube and ceramic soldering iron) may need replacing after several hundred hours of use. It is advisable to check connections and sensor calibration every 6-12 months to ensure thermal accuracy.
What functions does the Aoyue Int720 infrared soldering system combine?
It combines an infrared soldering tool, a soldering iron and a preheater in one 3-in-1 system.
What heating technology does it use?
It uses infrared wave heating technology instead of traditional hot air to prevent component movement.
What is the temperature range of the infrared tool?
The temperature range of the infrared tool is 0 to 480°C.
Where can I find accessories and spare parts for this system?
Accessories and spare parts are available on the manufacturer's official website www.aoyue.com.
Is the system covered by warranty?
The heating element and tips are excluded from warranty; the rest of the system may be subject to the manufacturer's terms.
