Aoyue INT738+ professional repair system with 60W soldering iron
Brand: Aoyue
VAT included (Ex VAT: 201.25 €)
Overview:
The Aoyue INT738+ professional repair system is a multifunctional soldering station designed for technicians and hobbyists who need precision and efficiency in electronic repair work. It combines three essential tools: a hot air gun, a 60W soldering iron, and a fume extractor, all controlled by a microprocessor with ESD function to protect sensitive components.
Main features:
- Microprocessor with ESD function to protect against electrostatic discharge.
- Digital display showing hot air, soldering iron and air pressure temperature, with touch panel for easy and precise control.
- Programmable auto-repair function from 20 to 9999 seconds to optimise soldering and repair processes.
- Self-check mode and sleep mode for energy saving and safety when not in use.
- Cooling function after unplugging that blows cold air until the temperature drops to 85ºC, extending the life of the heating element.
- Built-in extractor to remove harmful fumes and vapours, improving safety and environmental care.
- Compatible with different types of hot air nozzles, adapting to various applications.
Technical specifications:
- Power supply: 110V/220V.
- Dimensions: 188 x 126 x 250 mm.
- Weight: 5.6 kg.
Soldering iron:
- Power consumption: 60W.
- Temperature range: 200 - 480 ºC.
- Output voltage: 24V.
- Heating element: Ceramic base.
Hot air:
- Power consumption: 600W.
- Temperature range: 200 - 480 ºC.
- Air capacity: 23 l/min (maximum).
Typical uses:
Ideal for electronic repairs, equipment maintenance, soldering delicate components and tasks that require precise control of temperature and airflow. Its fume extraction function makes it suitable for environments where reducing exposure to harmful vapours is important.
Compatibility:
Compatible with different types of hot air nozzles, allowing it to adapt to various tasks and electronic components.
Important note: The heating element and tips are excluded from warranty.
- Microprocessor with ESD function for electrostatic protection
- Digital display with touch control for temperature and air pressure
- 3-in-1 system: hot air gun, soldering iron and fume extractor
- Programmable auto-repair from 20 to 9999 seconds
- Sleep mode and self-check for energy saving and safety
- Cooling function after unplugging to extend service life
- Built-in fume extractor for improved environmental safety
- Compatible with different hot air nozzles
- 60W soldering iron with 200-480 ºC temperature range
- Dual power supply 110V/220V, weight 5.6 kg
Customer Questions & Answers
What are the main technical specifications of the soldering iron and hot-air station, and what tolerances do they have for temperature and airflow?
The soldering iron operates at 60 W with an adjustable temperature range of 200 to 480 °C and a 24 V output; the hot-air unit consumes 600 W, covering the same thermal range and a maximum airflow of 23 L/min. The usual tolerance for temperature on this type of equipment is approximately ±3 °C, and for airflow ±10%.
What type of periodic maintenance does the station require to ensure durability and optimum performance?
It is recommended to regularly clean the fume extractor filters and make sure the nozzles are free from blockages. In addition, check the condition of the soldering iron and hot-air handpiece cables, and recalibrate the temperature if deviations are detected. Preventive replacement of certain consumables, such as tips and nozzles, extends the system’s service life.
Is the station compatible with 110 V and 220 V supplies, and what precautions should be taken when installing it?
Yes, the Aoyue Int738+ supports both voltages (110 V/220 V). It is essential to check the voltage selector before installation to avoid damage. Use only proper earthing and stable power sources; avoid using extension leads without surge protection.
What are the operating limits in terms of continuous use cycles, and what protection does it include against overheating or faults?
The station is designed for professional use and supports long cycles thanks to its automatic cooling function and programmable standby mode (10 minutes of inactivity). It includes self-check on start-up and thermal protection: when the temperature drops to 85 °C after use, cooling is activated to preserve the heater. However, as a precaution, pauses are recommended after prolonged use to ensure maximum durability.
What is the temperature range of the soldering iron on the Aoyue INT738+?
The soldering iron on the Aoyue INT738+ has a temperature range of 200 to 480 ºC.
What functions does the Aoyue INT738+ repair system combine?
It combines a hot air gun, a 60W soldering iron and a fume extractor in one device.
Is it compatible with different hot air nozzles?
Yes, the system is compatible with different types of hot air nozzles.
What does the cooling function after unplugging do?
After unplugging, the system blows cold air until the temperature drops to 85 ºC to protect the heating element and extend its service life.
Is the product currently available?
Currently, the product is out of stock and not available to buy.
