Aoyue 860 Hot Air Soldering Station for Professional SMD Work
Brand: Aoyue
VAT included (Ex VAT: 74.58 €)
The Aoyue 860 Hot Air Soldering Station is an essential tool for technicians and hobbyists who need precision and quality in soldering work, especially on SMD components. Its compact, stackable design allows efficient use of space on any workbench.
Main features:
- Durability and high performance for professional use.
- Compact design that takes up little space and is easy to handle.
- Includes a holder for hands-free use, making continuous work easier.
- Wide temperature adjustment range, from 100 to 500 ºC, ideal for different types of soldering.
Technical specifications:
- Power supply: 220V
- Power consumption: 250W
- Adjustable temperature: 100 - 500 ºC
- Heating element: ceramic
- Pump type: diaphragm pump
- Air capacity: 23 L/min (maximum)
- Dimensions: 132 mm (width) x 121 mm (height) x 192 mm (depth)
- Weight: 2.8 kg
In addition, we offer more than 50 different types of nozzles that can be purchased separately, as well as spare parts such as heating elements. For more information about spare parts or nozzles, you can send an email to info@satkit.com.
Typical uses:
- Repair and maintenance of SMD electronic components.
- Precision soldering on printed circuit boards.
- Electronics projects that require exact control of temperature and airflow.
Compatibility: Compatible with multiple Aoyue accessories and spare parts, specially designed to optimise performance.
Note: The heating element and tips are excluded from warranty.
Availability: This product is currently out of stock. For enquiries about availability or alternatives, please contact our customer service team.
- Durable, high-performance option for SMD work
- Compact, stackable design saves space
- Includes hands-free holder
- Wide temperature range from 100 to 500 ºC
- 220V power supply with 250W consumption
- Ceramic heating element for greater efficiency
- Diaphragm pump with 23 L/min air capacity
- Compact dimensions: 132x121x192 mm, weight 2.8 kg
- More than 50 nozzle types available separately
- Heating element and tips excluded from warranty
Customer Questions & Answers
What advantages does the diaphragm pump system offer compared with other systems in hot-air soldering stations?
The diaphragm pump system provides a more stable and less turbulent airflow compared with turbine pumps, resulting in better control when working with sensitive SMD components. However, it may produce more vibration and has a maximum airflow limit of 23 L/min, which is suitable for the usual SMD working range.
What are the dimensions and weight of the station, and what are the advantages of its compact, stackable design?
The station measures 132 mm wide, 121 mm high and 192 mm deep, with a weight of 2.8 kg. Its compact, stackable design saves space on workbenches and makes it easier to integrate into professional stations or workshops with limited space.
Are there any maintenance limitations, and how can frequent use affect the service life?
The main maintenance involves cleaning the nozzles and replacing consumable parts such as the heating element, which is not covered by warranty. Frequent use can shorten the service life of these parts, but with original spare parts and regular cleaning, optimum performance is maintained. It is recommended to check the internal condition of the pump every 12 months in intensive use.
What practical differences are there between the Aoyue 860 and other hot-air stations in a similar range in terms of power and precision?
The Aoyue 860 offers a maximum power of 250 W, suitable for standard SMD work, although it is below high-end models (>300 W). Its wide temperature range is competitive, but it lacks a precision digital display, which can limit fine control in critical applications. It stands out for its size and ease of use, although more advanced stations may offer better airflow regulation and thermal stability.
What is the maximum temperature of the Aoyue 860 soldering station?
The Aoyue 860 soldering station reaches a maximum temperature of 500 ºC.
Can I buy additional nozzles for this station?
Yes, we have more than 50 types of additional nozzles that can be purchased separately.
What is the power consumption of this soldering station?
The power consumption is 250W with a 220V power supply.
Is the Aoyue 860 soldering station available to buy now?
This product is currently out of stock. You can contact customer service to check availability or alternatives.
What type of pump does the Aoyue 860 station use?
It uses a diaphragm pump for hot air supply.
