Aoyue HHL3000 reflow oven with precise temperature control for professional soldering
Brand: Aoyue
VAT included (Ex VAT: 892.58 €)
The Aoyue HHL3000 reflow oven is an essential tool for professionals who require precise control in PCB soldering processes. This soldering oven offers an advanced temperature control system that ensures quality and reliability in every reflow.
Key features:
- Direct PCB temperature measurement that improves accuracy and reduces damage or distortion.
- Five controllable temperatures and times with automatic adjustment to suit different types of solder paste and circuit boards.
- Easy and quick reset of control points for precise tuning of reflow profiles.
- Construction with standard industry safety features, with temperature control from 0.01ºC to 3ºC.
- Fully digital control panel for quick monitoring of time and temperature.
- High compatibility with lead-free applications, meeting current regulations.
Technical specifications:
- Power input: 110V / 220V.
- Dimensions: 360 mm (length) x 385 mm (width) x 190 mm (height).
- Weight: 15 kg.
- Temperature range: 100°C - 250°C.
- Heating element type: Infrared.
- Valid soldering area: 210 mm x 190 mm.
- Standard reflow time: 4 to 8 minutes.
Typical uses:
This reflow oven is ideal for PCB soldering in electronics manufacturing and repair processes, especially in environments that require high precision and temperature control to avoid damage to sensitive components. Its compatibility with lead-free soldering makes it suitable for modern and environmentally friendly applications.
Compatibility:
Compatible with different types of solder pastes and circuit boards, the Aoyue HHL3000 is a versatile solution for workshops and electronics production lines.
Important note: This product is currently out of stock. We recommend checking alternative products or contacting us for more information about future availability.
- Direct temperature measurement for greater accuracy and less damage.
- Five temperature and time levels with automatic adjustment.
- Digital panel for easy control and monitoring of settings.
- Compatible with lead-free soldering and different solder pastes.
- Compact dimensions and manageable weight for easy installation.
Customer Questions & Answers
What advantages does digital temperature control offer over analogue models in reflow ovens such as the Aoyue Hhl3000?
The digital temperature control of the Aoyue Hhl3000 allows precise, repeatable adjustments, delivering greater thermal stability and minimising drift during the reflow process. This is especially important for lead-free soldering, which requires narrow thermal windows. Unlike analogue models, digital control makes it easier to set and recall temperature profiles, improving traceability and reducing errors.
Is any additional fume extraction system needed when using the Aoyue Hhl3000 reflow oven?
Although the Aoyue Hhl3000 does not have built-in fume extraction, fumes are generated during the reflow soldering process and may contain toxic compounds, especially when working with flux or lead-free solder. It is recommended to install an external fume extractor or ensure good ventilation in the work area to meet health and safety requirements.
What margin of error does the direct PCB temperature measurement system have, and how does it affect reflow quality?
The oven includes a direct PCB temperature measurement system with a tolerance of ±0.01ºC to ±3ºC, depending on the position and thermal mass of the board. This margin ensures that the temperatures reached remain within the critical soldering range, reducing the risk of overheating or cold joints. However, local variations in very dense boards may require fine adjustment of the thermal profile.
What type of maintenance does the infrared heating element require, and what is its estimated service life?
The infrared heating element needs periodic checks for dust build-up or obstruction, which can affect heat distribution. It is recommended to clean the interior every 6 months. The typical service life for this type of heating element is approximately 5,000-8,000 hours of regular use, although this may vary depending on the thermal cycle applied and the unit’s ventilation.
What is the temperature range of the Aoyue HHL3000 reflow oven?
The temperature range is 100°C to 250°C, suitable for different soldering processes.
What type of heating element does it use?
It uses an infrared heating element for even and efficient heating.
Is it compatible with lead-free soldering?
Yes, the oven is highly compatible with lead-free soldering applications.
What are the oven dimensions?
The dimensions are 360 mm long, 385 mm wide and 190 mm high.
Is it currently available to buy?
The product is currently out of stock. Future availability or alternative products are recommended.
