Aoyue INT2702A+ soldering station with digital control and advanced functions
Brand: Aoyue
VAT included (Ex VAT: 269.10 €)
Aoyue INT2702A+ Soldering Station
The Aoyue INT2702A+ soldering station is a professional tool designed for electronic soldering work that requires precision and advanced control. This station integrates a microprocessor-controlled ESD system that allows digital management of the temperature of its main components: the soldering iron, hot air gun and desoldering gun, as well as easy air pressure control from its control panel.
Main features:
- Microprocessor-controlled ESD unit to prevent damage from static electricity.
- Digital temperature control for soldering iron, hot air and desoldering gun.
- Desoldering tool with a design that prevents electrical surges and equipped with a suction pump for a strong and constant airflow.
- 24 V soldering iron with a compact design that integrates a ceramic heater, sensor and nozzle for efficiency and easy tip replacement.
- Auto-fan system that cools the unit automatically when switched off to extend the service life of the heating components.
- Compatible with multiple types of air nozzles and soldering tips (LF reference).
Technical specifications:
- Power input: 220 V
- Dimensions: 188 x 126 x 250 mm
Soldering iron:
- Consumption: 70 W
- Temperature range: 250-480 ºC
- Heating element: Ceramic
- Output voltage: 24 V
Hot air gun:
- Power consumption: 500 W
- Temperature range: 100-480 ºC
- Heating element: Metal
- Diaphragm pump
- Air capacity: 23 l/min (max.)
Desoldering gun:
- Temperature range: 380-480 ºC
- Output voltage: 36 V
- Heating element: Ceramic
- Suction flow: 15 l/min (max.)
- Pressure: 600 mm Hg
Use and compatibility:
This station is ideal for professionals and advanced hobbyists working on repair and maintenance of electronic circuits, automotive applications, electronic measuring equipment and other devices that require precise, controlled soldering. Its compatibility with different nozzles and tips makes it easy to adapt to a variety of tasks and soldering types.
Important note: This product is currently out of stock. We recommend checking alternative products or subscribing to receive availability notifications.
*** The heating element and tips are excluded from warranty ***
- Microprocessor-controlled ESD unit for static protection
- Digital temperature control for soldering iron, hot air and desoldering gun
- Desoldering tool with suction pump and surge protection
- 24V soldering iron with ceramic heating element and easy nozzle replacement
- Auto-fan system cools the unit to extend service life
- Compatible with multiple air nozzles and soldering tips (LF reference)
- 220V power input and compact dimensions (188x126x250 mm)
- Hot air gun with 500W consumption and 23 l/min air capacity
- Desoldering gun with 15 l/min suction flow and 600 mm Hg pressure
Customer Questions & Answers
What components are included in the box of the Aoyue Int2702a+ Soldering Station and what are their main materials?
The box usually includes the main station, soldering iron (24V), hot-air handpiece, desoldering gun, some nozzles/tips, stand, power cables and manual. The main construction materials are durable plastics (housing), metal for the nozzles and heating elements (ceramic for the soldering iron, metal for hot air), and electronic components inside. The supplied accessories may vary depending on the batch or distributor.
What safety systems and standards does this station comply with to prevent overheating or electric shocks?
The unit features ESD protection via microprocessor control, an automatic fan that cools down to 85°C after use, and digital temperature control to prevent overvoltage. The desoldering gun has electrical insulation to prevent current leakage. CE or IEC certification is not explicitly specified, but the design reflects standard safety measures for professional equipment.
What is the actual temperature range and stability of the soldering iron and hot-air gun?
The soldering iron operates between 250–480°C (70W consumption, ceramic heater, typical accuracy ±10°C), and the hot-air gun between 100–480°C (500W, metal heater, approx. ±15°C accuracy), both digitally controlled. Stability is suitable for electronics projects, although performance may vary slightly in very cold environments or under demanding continuous use.
What are the electrical requirements and voltage considerations for installation?
The station requires a stable 220V AC supply and proper earthing. It is essential to check compatibility with the local mains supply, as it is not designed for 110V. The internal soldering iron operates at 24V, generated by the station itself. Maximum consumption is approximately 570W when used together (hot air and soldering iron).
What is the temperature range of the soldering iron?
The soldering iron has an adjustable temperature range between 250 and 480 ºC.
What type of heating element does the hot air gun use?
The hot air gun uses a metal heating element.
Is it compatible with different types of nozzles?
Yes, it is compatible with various types of air nozzles and soldering tips with LF reference.
What output voltage does the desoldering gun have?
The desoldering gun has an output voltage of 36 V.
Is the product available for immediate dispatch?
The Aoyue INT2702A+ soldering station is currently out of stock and not available for immediate dispatch.
