Protoshield Prototyping Board with Mini Breadboard for Arduino

Name: Protoshield Prototyping Board with Mini Breadboard for Arduino
Brand: satkit
SKU: A030101-proto-uno
Price: 4.55 EUR
Availability: InStock

Brand: satkit

Be the first to review this product

4.55€

VAT included (Ex VAT: 3.70 €)

Volume Discounts

Quantity	Price	Save
2+	4.37 €	-4%
10+	4.14 €	-9%
20+	3.64 €	-20%

In Stock - Ships immediately

Standard delivery Mon, May 4 - Wed, May 6

Express delivery Thu, Apr 30 - Fri, May 1

30-day returns

Quantity

Free returns within 30 days

Secure transaction

Free Delivery Shipping from €4.99

Easy Returns 30 day return policy

Secure Payment 100% secure checkout

Quality Guarantee Original products only

The Protoshield Prototyping Board with Mini Breadboard for Arduino is an essential tool for developers and hobbyists looking to create prototypes quickly and efficiently. This board combines the functionality of an Arduino shield with an integrated mini breadboard, allowing temporary connections without the need for soldering.

Key features:

Includes 1 reset button and 1 general-purpose button to make it easier to control your projects.
Features 2 built-in LED circuits to indicate states or activity.
Exposed key pins: 5V, GND and Raw for direct electrical connections.
SOIC area for easy integration of integrated circuits (IC).
Mini breadboard with 170 tie points for versatile, tidy connections.
Self-adhesive backing that allows the board to be fixed to different surfaces for greater stability.
Compact size of 4.4 x 3.4 x 1 cm, ideal for projects with limited space.

Typical uses:

Rapid prototyping of electronic circuits with Arduino.
Development of DIY projects and electronic hobby kits.
Testing and experiments with electronic components without soldering.
Education and learning in electronics and Arduino programming.

Compatibility: This board is specifically designed to be compatible with standard Arduino boards, making it easy to integrate into existing and new projects.

With this board you can streamline your prototype development workflow, combining the convenience of the breadboard with the additional functions of an Arduino shield. Its compact, practical design makes it an essential accessory for any electronics enthusiast.

1 built-in reset button and 1 general-purpose button
2 LED circuits for visual indication
Exposed 5V, GND and Raw pins for easy connections
SOIC area for integrating integrated circuits (IC)
Mini breadboard with 170 tie points for versatile prototyping
Self-adhesive backing for secure mounting
Compact size of 4.4 x 3.4 x 1 cm, ideal for tight spaces

Customer Questions & Answers

What are the exact dimensions and weight of the board and breadboard?

The mini breadboard measures 44 mm x 34 mm x 10 mm. The shield, compatible with Arduino Uno, measures approximately 68.6 mm x 53.4 mm x 1.6 mm. The set weighs about 38 g in total.

What advantages does using this protoshield offer compared with soldering directly on a breadboard?

The Protoshield allows solder-free prototyping using the removable breadboard, making quick changes easier and avoiding permanent mistakes. It also exposes pins and adds integrated buttons and LEDs for testing, unlike a standard breadboard.

What is the maximum safe current per track on the protoshield?

The standard copper tracks on this shield support up to 1 A safely, although it is recommended to limit this to 0.5 A to minimise heating and preserve integrity with repeated connections.

Do I need special tools to install the shield on Arduino?

Installation is straightforward: simply plug it into the Arduino headers, with no additional tools required. The mini breadboard can be attached or removed as needed.

What is the Protoshield prototyping board with mini breadboard for Arduino used for?

It is used to make rapid prototyping of electronic circuits with Arduino easier, allowing solder-free connections and integrated buttons and LEDs.

Is this board compatible with all Arduino boards?

It is designed to be compatible with standard Arduino boards, making it easy to integrate into most Arduino projects.

How many tie points does the mini breadboard have?

The integrated mini breadboard has 170 tie points for versatile connections.

What buttons does the board include?

It includes a reset button and a general-purpose button for easy project control.

Does the board have a way to fix it in place?

Yes, it has a self-adhesive backing that allows the board to be fixed to different surfaces for greater stability.
