Siglent SDS1102X 2-Channel Digital Oscilloscope with 100 MHz Bandwidth
Brand: Siglent
VAT included (Ex VAT: 399.00 €)
Volume Discounts
| Quantity | Price | Save |
|---|---|---|
| 2+ | 471.14 € | -4% |
| 10+ | 461.32 € | -6% |
| 20+ | 441.69 € | -10% |
The Siglent SDS1102X Digital Oscilloscope is an advanced measurement instrument designed for professionals and electronics enthusiasts who require precision and high fidelity in signal analysis. This model features two channels and a 100 MHz bandwidth, allowing complex signals to be captured in great detail.
With a real-time sampling rate of up to 1 GSa/s and a standard record length of 14 Mpts, the SDS1102X ensures accurate and efficient waveform capture, even on fast or transient signals. Its innovative SPO technology provides excellent signal fidelity and low noise, ensuring reliable results.
Key features:
- Two channels for simultaneous signal analysis.
- 100 MHz bandwidth for a wide range of electronic applications.
- 1 GSa/s sampling rate for capturing fast signals with high resolution.
- 14 Mpts record length allowing large amounts of data to be stored for detailed analysis.
- Refresh rate of up to 60,000 waveforms per second, making it easier to detect anomalies.
- Vertical sensitivity from 500 µV/div to 10 V/div to suit different signal levels.
- Switchable input impedance between 1 MΩ and 50 Ω, compatible with various signal sources.
- 8" colour LCD-TFT display with 800 x 480 pixel resolution and 256 intensity levels for clear, detailed viewing.
- Advanced trigger functions including Pattern, Window, Interval, DropOut, Runt and HDTV for capturing specific events.
- Optional protocol decoding for I2C, SPI, UART/RS232 and CAN, making digital communications analysis easier.
- Built-in maths operations: addition, subtraction, multiplication and division, plus FFT, integration, differentiation and root functions.
- Segmented memory with up to 1,000 segments and recording of up to 80,000 frames for in-depth analysis.
- USB and LAN connectivity for data transfer and remote control.
Typical uses: The Siglent SDS1102X is ideal for electronics labs, circuit development, industrial maintenance and technical education. Its ability to capture fast and complex signals makes it suitable for digital device testing, communications analysis and circuit debugging.
Compatibility: Compatible with multiple communication protocols and with USB and LAN interfaces, this oscilloscope integrates easily into modern work environments and automated test systems.
The product is currently out of stock. We recommend checking alternatives or contacting us for information on future availability.
- 2 channels for simultaneous analysis
- 100 MHz bandwidth
- 1 GSa/s sampling rate
- 14 Mpts record length
- Refresh rate up to 60,000 wfm/s
- Vertical sensitivity from 500 µV/div
- Switchable 1 MΩ and 50 Ω input impedance
- 8" colour LCD-TFT display
- Advanced trigger functions
- Optional protocol decoding for I2C, SPI, UART/RS232, CAN
- Math functions and FFT
- Segmented memory and signal recording
- USB and LAN connectivity
Customer Questions & Answers
What advantages does advanced SPO technology offer for signal capture compared with conventional digital oscilloscopes?
The SPO (Super Phosphor Oscilloscope) technology used in the Siglent SDS1102X provides greater signal fidelity and lower background noise compared with conventional digital oscilloscopes. This helps display details of repetitive or very fast signals and assists in identifying infrequent events thanks to a refresh rate of up to 60,000 wfms/s. As a result, diagnosis and debugging of electronic circuits is faster.
What are the materials, dimensions and weight of the Siglent SDS1102X?
The Siglent SDS1102X is mainly built from high-strength ABS and aluminium in the internal heatsinks. Its approximate dimensions are 340 mm x 157 mm x 122 mm and its weight is 2.5 kg, making it easy to handle in laboratory or field environments.
Is the oscilloscope compatible with analysis software, and what connectivity interfaces does it include?
The SDS1102X is compatible with Siglent EasyScopeX software for Windows. It includes USB ports (host and device), 10/100 Ethernet LAN, and VGA output/pass-through. This makes it easier to integrate into automated test benches and transfer data to PCs and local networks.
What maintenance does the Siglent SDS1102X require to ensure durability?
Recommended maintenance includes periodic cleaning of the exterior with a dry cloth, checking the BNC connectors and USB contacts to remove dust or residue, and avoiding exposure to excessive heat sources or high humidity (>80% RH). It is important to ensure the ventilation openings remain clear to prevent overheating during prolonged use.
What warranty coverage does Siglent offer, and how are spare parts or after-sales support handled?
Siglent offers a standard 3-year warranty for the SDS1102X in most regions, covering manufacturing defects. Common spare parts such as probes, cables or fuses are available through authorised distributors. After-sales support includes technical assistance and firmware updates, although the exact scope may vary depending on the distributor.
How many channels does the Siglent SDS1102X oscilloscope have?
The Siglent SDS1102X oscilloscope has 2 channels for simultaneous signal analysis.
What is the bandwidth of the Siglent SDS1102X?
The bandwidth is 100 MHz, suitable for a wide range of electronic applications.
What sampling rate does this oscilloscope offer?
It offers a sampling rate of up to 1 GSa/s for capturing fast signals with high accuracy.
Is the Siglent SDS1102X oscilloscope in stock?
The product is currently out of stock. It is recommended to check alternatives or contact us for future availability.
What connectivity options does this oscilloscope have?
It has USB (host and device) and LAN connectivity for data transfer and remote control.
